Solar Panel DS10 144-550M

AED: 280.00

SKU: DS10144550M Category: Tag:
Quick Specs
Pmax: 550 W Voc : 49.79 V Isc : 14 A
Vmpp : 41.27V Impp : 13.33 A Cell:  MONO PERC
Features
  • Dubai based solar PV modules manufacturer with total 150MWp total production capacity.
  • 1500Vdc modules – maximum system voltage
  • TUV certificates for IEC standards.
  • DEWA, ADDC, FEWA, SEWA approved modules.
  • 5BB, 12BB range with conventional back sheet frame and frameless glass-glass modules

63 in stock

For more information
+971 4 552 4462
info@maxima.solar

63 IN STOCK

Introduction

DUSOL’s – sister company of MAXIMA with manufacturing facility in UAE – Standard range of solar panels are made using standard cells without making any alteration to the cell’s physical and/or electrical characteristics. The standard range of DUSOL modules consists of either 36, 60 or 72 cells interconnected to elevate the voltage and keep the current equal to the cells’ current. Careful consideration in matching the characteristics of the cells is undertaken to maximize the power output by reducing cell-to-module losses.

General Description

As a solar specialist with more than 30 years of experience in photovoltaic (PV), DuSol has made and continues to makes significant contributions to undertaking groundbreaking progress in solar technology. Dusol photovoltaic modules are designed for applications with high power requirements. These quality MONO-PERC modules produce a continuous, reliable yield, even under demanding operational conditions. All DuSol DS series modules offer syştem integration configurations which are optimal both technically and economically and are suitable for installations in on- and off-grid PV systems.

Future

High-performance photovoltaic modules made of MONO-PERC (158.75 mm) 2 silicon DuSol solar cells with module efficiencies of 20.5% or higher.

  1. 5 busbar technology for enhancing the power output.
  2. Anti-reflex coating to increase light absorption.
  3. Production controlled positive power tolerance from 0 to +5%.
  4. Only modules will be delivered that have specific power or more for high energy yield.

Only modules will be delivered that have specific power or more for high energy yield.

  1. Delivery of modules in -watt intervals.
  2. Improved temperature coefficient to reduce power losses at higher temperatures.
  3. High power performance even at lower irradiation.

Quality PV modules From DUSOL

Continual checks guarantee a consistently high level of quality. Every module undergoes visual, mechanical, and electrical inspection. This is recognizable by means of the original DuSol label, the serial number, and the DuSol guarantee:

  1. 10 years product guarantee.
  2. 25 years linear performance guarantee.
  3. Minimum 96% of the specified minimum power output during the first year.
  4. Modular design gives the end customers the power of choice of capacity.
  5. Compatible with most of the available Hybrid inverters.
  6. Maximum 0.667% annual reduction of the power output for the following 24 years.
Weight 28.50 kg
Dimensions 2279 × 1134 mm
