Lynx Distributor – M8
AED: 1,085.00
Quick Specs
| Voltage: 9-60 Vdc | Rev. Pol Protect: Yes | Current: 1000 Adc |
|---|---|---|
| BBar: M8 | Fuses: M8 | Power: RJ10 |
Features
- Each fuse monitoring
- Local and remote monitoring of fuses
- RJ10 for power and data transmission is included
- Part of Lynx distribution system
- Space for 4 fuses, one for each DC circuit
2 in stock
Introduction
A modular DC busbar with spaces for four DC fuses. It monitors the status of each fuse and displays its condition with an LED on the front. The Lynx Distributor is part of the modular Lynx distribution system, available as M8 and M10 models.
General Description
The Lynx Distributor contains a positive and a negative busbar. The positive busbar has four fuse-protected connections with fuse monitoring. The negative busbar has four connections and a ground connection.
M8, M10 Versions
It is part of the Lynx Distribution system and is available in two versions, with M8 or M10 busbar. Note that M10 refers to the busbar connection joints where the modules are connected to each other. The fuse and cable connections are always M8.
Status of Fuses on APP
It is part of the Lynx Distribution system and is available in two versions, with M8 or M10 busbar. Note that M10 refers to the busbar connection joints where the modules are connected to each other. The fuse and cable connections are always M8.
GX Device
Up to 4 connected Lynx Distributors can be monitored with a GX device if connected to a Lynx Smart BMS.The GX device can be connected to the VRM portal, allowing remote monitoring.
| Weight | 0.8 kg |
|---|---|
| Dimensions | 252 × 127 × 78 mm |
